Vieser low model extension ring 18mm

EXTENSION RINGS

The Vieser low extension ring is meant to be used with Vieser floor drains below the waterproofing. The low extension ring is suitable for floor slope adjustments, renovations and installation of underfloor electric heating.

  • Type approved
  • The low extension ring raises the floor drain by 18 mm.
  • A low extension ring must always be the uppermost extension ring, and it cannot be extended with another extension ring.
  • Compatible with all Vieser floor drains

The package contains an extension ring, white lip seal, grey clamping ring and white support ring.

Read more

Please note:

a grey clamping ring is included in the package. The grey clamping ring is meant to be used with this extension ring type only. A white clamping ring is supplied with all other Vieser extension rings and floor drains. The white lip seal and grey clamping ring are meant to be used with a low extension ring only, and they are not compatible with other Vieser products.

A low extension ring must always be the uppermost extension ring and it cannot be extended with another extension ring.

Avainlippu
Vieser no51183
EAN6418685511836
LVI3318952
MaterialPolypropylene (PP)
Packaging (box/pallet)8/320
Product dimensions178 x 178 x 40mm
Product weight0.3 kg
